Water Heater Breaker Size Requirements 2025

Choosing the right circuit breaker size for your water heater is a matter of safety and performance.

Water heaters are big power users, and they demand proper electrical protection to run safely and not cause dangerous situations or appliance failures. This guide should give you everything you need to select the correct circuit breaker for various water heater types and understand the relevant electrical requirements (plus a few necessary codes and good practices).

Water heaters are devices with high electrical loads that have to have circuits and breakers that are sufficiently sized. What goes into determining whether the water heater has been supplied with a circuit and a breaker of sufficient size? Three interrelated factors: wattage, voltage, and amperage. These factors in turn determine how much power the water heater sucks up.

The majority of household electric water heaters run on 240-volt circuits (which need a double-pole breaker), while gas water heaters with electronic ignition typically use 120-volt circuits. The size of the circuit breakers must match the appliances they serve and must also provide appropriate overcurrent protection.

The main equation for determining amperage is this: Amps = Watts ÷ Volts.

If we use that to look at a 4500-watt, 240-volt water heater, the amperage works out to be 18.75 amps. Following the National Electrical Code (NEC), we must size breakers at 125% of continuous load, which affects water heater circuit requirements.

Water Heater Type	Voltage	Common Wattage	Standard Breaker Size
Small Tank (30 – 40 gal)	240V	3,800-4,500W	20 – 30A
Large Tank (50 – 80 gal)	240V	4,500-5,500W	30A
Tankless Electric	240V	7,000-28,000W	30 – 150A
Gas Water Heater	120V	500-1,500W	15A

Calculating the Correct Breaker Size

Choosing an appropriate breaker size requires moving through several stages:

Verify wattage and voltage specifications against the nameplate data of the water heater.

To find the amps, use the formula: Amps = Watts divided by Volts.

To get the proper wire size for an application, we must 1. Calculate the necessary amperage for that application based on the voltage drop and available voltage. 2. Size the wire to the calculated amperage, using NEC standards as a basis for proper wire-sizing practices. 3. Consider adjustment and correction factors that may apply to the specific installation of that wire.

Choose the following standard circuit breaker size larger than your computation.

Say, for instance, your water heater pulls 18.75 amps (4500W ÷ 240V). You would multiply that by 1.25 to get 23.44 amps. And because regular-sized circuit breakers are either 20 amps or 30 amps, you’d go with the 30-amp circuit breaker for this service.

Standard Water Heater Breaker Sizes by Type

Electric Tank-Style Water Heaters

The typical electric water heater found in homes requires a double-pole circuit breaker rated at 30 amps.

These units mostly run on 240 volts, with heating elements that draw anywhere from 3,800 to 5,500 watts. Smaller electric water heaters, which may operate on as few as 3,500 watts, are sometimes sold as portable units and can get by with 20 or 25-amp breakers.

The average home electric water heater has two heating elements. Although the total wattage of both elements is 5,500 watts, they alternate and do not work at the same time; therefore, 5,500 watts is used for breaker sizing, not 11,000 watts.

Tankless Electric Water Heaters

Demand for electricity is high with electric water heaters that are tankless.

These patio powerhouses push the limits and requirements with how much energy they consume. Not even the standard services that power contemporary American homes can handle a whole-house heater’s needs, which can range from 8,500 watts to 27,000 watts. That’s more than some power tools, and it’s obviously way more than what most runs in a typical American home.

Elements of the equation that we haven’t even discussed yet—dedicated breaker circuits, service panels, and wiring—push the 240-volt aspect even harder. These on-demand systems often require multiple dedicated circuits.

Yes, electric tankless water heaters push the limits and requirements with how much energy they consume.

A tankless water heater with a 24kW output working at 240 volts would pull 100 amps. This might mean installing three 40-amp circuits fed by appropriately gauged wire.

Such upgrades are often required because tankless water heating is a new service in the home, not an extension of an existing one. Any service to the tankless system could mean serious upgrades to the home electrical system.

Gas Water Heaters

Commonly found in gas water heaters that boast either electronic ignition or control boards, wiring usually follows a standard electrical installation of a 15-amp, 120-volt circuit.

Because such heaters use electricity mainly for controls and ignition, their electrical demand is substantially lower than that of electrically powered water heaters.

Although the requirements for electricity are minimal, gas water heaters still need dedicated circuits to guarantee dependable operation and to meet building codes.

The National Electrical Code specifies that circuits serving gas water heaters may not also serve other appliances or outlets.

Wire Size Considerations

The size of the circuit breaker tells you what wire gauge you must use. If you use a gauge that is too small, it could overheat, even if it is not carrying enough current to trip the breaker. And if you use a wire gauge that is too big, it could cost a lot more than necessary to install.

Here are standard wire size requirements for water heater circuits:

• 15-amp circuit: 14-gauge wire
• 20-amp circuit: 12-gauge wire
• 30-amp circuit: 10-gauge wire
• 40-amp circuit: 8-gauge wire
• 50-amp circuit: 6-gauge wire.

Note: You must also factor in the wire size and distance from the electrical panel when dealing with voltage drop. If your water heater is located more than 100 feet from the electrical panel, you should increase the wire gauge by one size to make up for the resistance losses in the wire.

3 Factors That Affect Breaker Size Requirements

Water Heater Capacity

Generally, water heaters that are larger in size require bigger wattage heating elements to efficiently heat not only a greater volume of water but also to do it in a timely fashion, and this sometimes results in the need for larger circuit breakers.

For instance, a 40-gallon water heater might work just fine with a 3,800-watt element, while an 80-gallon unit might actually require 5,500 watts or more to effectively serve that same 80-gallon hot water supply.

Tank dimensions and required energy components don’t relate in a straightforward way.

Insulation quality and energy efficiency ratings can cause the specifications of heating elements (and the circuits they require) to vary significantly. Consequently, the relationship between dimensional increases and demanded energy is often not linear.

Breakers need to accommodate these circuit changes.

Regional Climate Considerations

Water heaters in colder climates have a tougher job.

They labor longer and harder to elevate the temperature of the water flowing into them from the municipal supply. Sometimes, the upshot of that harder work is an insistence from manufacturers that you buy a model with more watts if you live up north.

And that, thanks to ohm’s law, has an effect on the wire and breaker size you need.

In cold climates, electric water heaters located in garages, basements, or other unheated spaces might draw more electricity than heaters situated in warm spaces, creating potential problems for breaker selection and overall electrical system design.

Recovery Rate Requirements

How fast the water heater can reheat water in a new tank after it has been used up affects how many watts it needs to use.

If your house uses a lot of hot water, you may have a water heater that has more wattage going to it to boost the recovery rate so you have sufficient hot water to use.

These high-wattage appliances need higher-rated circuit breakers.

A water heater that is appropriate for a family of six and has faster recovery than one that’s right for a single person may well require more electrical circuit capacity.

Upgrades and Replacements

When you replace an old water heater, make sure to match the new energy-efficient model with the current electrical setup.

Modern up-to-code appliances sometimes have very different requirements, and assumptions can lead to fires.

When upgrading to a water heater with a larger capacity or to a tankless model, it’s likely your electrical circuit will also need upgrading.

This is especially true when transitioning from a traditional tank-style heater to a tankless electric model, which can demand several circuits with high amperage.

Do not ever presume that the electrical circuit you currently have in place can sufficiently support a water heater of new variety without you first verifying whether it can.

Check the data on the nameplate and consult with an electrician of good standing if the new unit has different kinds of electrical specifications.

National Electrical Code Requirements

The National Electrical Code (NEC) creates the criteria for safe electrical installations and covers aspects of water heaters.

The NEC covers water heater specifics in sections 422 and 430.

If you want to get into the nitty-gritty, you need to read the code, which is what this article aims to summarize.

The code necessitates that continuous load circuits be sized at 125% of the continuous load.

Thus, this means a water heater that draws 24 amps would require a circuit rated to handle at least 30 amps (24 × 1.25 = 30).

Moreover, dedicated circuits for water heaters are mandated by the NEC, clearly stipulating that the circuits cannot serve any other outlets or appliances.

This guarantees that the water heater has the full electrical capacity it needs, without having to share the load with any other of its kind either.

Professional vs. DIY Considerations

When deciding on the proper size of the circuit breaker, the process involves simple, direct calculations.

However, the installation or upgrading of electrical circuits for water heaters is usually best left to professionals.

This is because most permits and inspections associated with water heater installations—and also with any modifications to the home’s electrical system—mandate that a qualified electrician do the work.

240-volt circuits with high amperage are dangerous.

They present shock hazards, fire risks, and potential code violations if the work is done incorrectly. Unless you’re a qualified electrician, you shouldn’t be doing this kind of work.

That goes double for the 240-volt circuits that service your electric water heater.

Professional installation usually costs between $300 and $800 for basic water heater circuit work, but complex installations or service upgrades can run much higher

This is a good investment for ensuring that your water heater is operating safely, satisfactorily, and in compliance with local codes.
